Charge controller Bluesolar PWM Pro 12V/24V-20A

Charge controller Bluesolar PWM Pro 12V/24V-20A

BlueSolar charge controller with PWM Pro 12V / 24V-20A.
PWM controller 20A 12V / 24V.

Ised the battery in three phases: (maximum load, absorption and flotation) is achieved thereby extend the life of the battery. Protect and optimize the life of the solar installation.

Lighting control function, fully programmable.

Prevents battery discharge at night by the effect return to the solar panel.

* Technical support not included. Eligible separately here.

VICTRON BlueSolar PWM-Pro 20A
€45.00
Tax included
In stock



Secure payment



Shipping policy



Return policy

BlueSolar PWM-Pro solar charge controllers

Programmable
The BlueSolar PWM-Pro series is ready for use with its default settings. It also is fully programmable.

Features

  • Lighting control function, fully programmable.
  • Three stage battery charging (bulk, absorption, float), fully programmable
  • Integrated battery monitor function (Remote Panel needed to display state of charge).
  • Load output with low voltage disconnect and manual control (default setting).
  • Optional external temperature sensor.
  • Load output protected against over load and short circuit.
  • Protected against reverse polarity connection of the solar panels and/or battery.

Day/night timing options
See Remote Panel manual for details.

Download Technical Sheet Controller Bluesolar PWM Pro
