Victron Phoenix Inverter Compact 2000VA 12V

Victron Phoenix Inverter Compact 2000VA 12V

SinusMax - Superior design

Developed for professional usage, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem-free, to any charge.

Extra start-up power

A unique feature of the SinusMax technology is very high start-up power. Conventional high frequency technology does not offer such outstanding performance. Phoenix inverters, however, are well suited to power up difficult loads such as refrigeration compressors, electric motors and similar appliances.

Nearly unlimited power thanks to parallel and 3-phase operation capability

Up to 6 inverter units can operate in parallel to achieve higher power output. Six 24/5000 units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible. To transfer the load to another AC source: the automatic transfer switch If an automatic transfer switch is required we recommend using the MultiPlus inverter/charger instead. The switch is included in these products and the charger function of the MultiPlus can be disabled. Computers and other electronic equipment will continue to operate without disruption because the MultiPlus features a very short switchover time (less than 20 milliseconds).

Computer interface

All models have a RS-485 port. All you need to connect to your PC is our MK2 interface (see under "Accesories"). This interface takes care of galvanic isolation between the inverter and the computer, and converts from RS-485 to RS-232. A RS-232 to USB conversion cable is also available. Together with our VEConfigure software, which can be downloaded free of charge from our website www.victronenergy.com, all parameters of the inverters can be customised. This includes voltage and output frequency, over and under voltage settings and programming the relay. This relay can for example be used to signal several alarm conditions, or to start a generator. The inverters can also be connected to VENet, the new power control network of Victron Energy, or to other computerised monitoring and control systems.

New applications of high power inverters

The possibilities of paralleled high power inverters are truly amazing. For ideas, examples and battery capacity calculations please refer to our book “Electricity on board” (available free of charge from Victron Energy and downloadable from www.victronenergy.com).

•      Equipment of pure sine wave: They mostly used for all applications and allows feeding sensitive electronic equipment.

•      Yields> 90%

•      Input voltage 12Vdc and 220Vac output

•      Toroidal transformer: High Performance

•      Controlled by microprocessor: excellent protection against misuse

•      Battery Cables included: easy to install

•      IEC-320 Package

•      Total electronic protection

•      Dimensions: 520x255x125 mm

•      Weight: 12.0 kg
